类别 Item | 型号 (高度×宽度) (H×W) | 载面尺寸Section,mm | 载面面积 Sectio Area(cm2) | 理论重量 theoretical kg/m | 载面特性参数 Sextion data | ||||||||
H×B | t1 | t2 | r | 惯性矩 cm4 | 惯性半径cm | 载面模数 cm3 | |||||||
Ix | Iy | ix | iy | Wx | Wy | ||||||||
HN | 100×50 | 100×50 | 5 | 7 | 10 | 12.16 | 9.54 | 192 | 14.9 | 3.98 | 1.11 | 38.5 | 5.98 |
125×60 | 125×60 | 6 | 8 | 10 | 17.01 | 13.3 | 417 | 29.3 | 4.95 | 1.31 | 66.8 | 9.75 | |
150×75 | 150×75 | 5 | 7 | 10 | 18.16 | 14.3 | 679 | 49.6 | 6.12 | 1.65 | 90.6 | 13.2 | |
175×90 | 175×90 | 5 | 8 | 10 | 23.21 | 18.2 | 1220 | 97.6 | 7.26 | 2.05 | 140 | 21.7 | |
200×100 | 198×99 | 4.5 | 7 | 13 | 23.59 | 18.5 | 1610 | 114 | 8.27 | 2.20 | 163 | 23.0 | |
200×100 | 5.5 | 8 | 13 | 27.57 | 21.7 | 1880 | 134 | 8.25 | 2.21 | 188 | 26.8 | ||
250×125 | 248×124 | 5 | 8 | 13 | 32.89 | 25.8 | 3560 | 255 | 10.4 | 2.78 | 287 | 41.1 | |
250×125 | 6 | 9 | 13 | 37.87 | 29.7 | 4080 | 294 | 10.4 | 2.79 | 326 | 47.0 | ||
300×150 | 298×149 | 5.5 | 8 | 16 | 41.55 | 32.6 | 6460 | 443 | 12.4 | 3.26 | 433 | 59.4 | |
300×150 | 6.5 | 9 | 16 | 47.53 | 37.3 | 7350 | 508 | 12.4 | 3.27 | 490 | 67.7 | ||
350×175 | 346×174 | 6 | 9 | 16 | 53.19 | 41.8 | 11200 | 792 | 14.5 | 3.86 | 649 | 91.0 | |
350×175 | 7 | 11 | 16 | 63.66 | 50.0 | 13700 | 985 | 14.7 | 3.93 | 782 | 113 | ||
400×150 | 400×150 | 8 | 13 | 16 | 71.12 | 55.8 | 18800 | 734 | 16.3 | 3.21 | 942 | 97.9 | |
400×200 | 396×199 | 7 | 11 | 16 | 72.16 | 56.7 | 20000 | 1450 | 16.7 | 4.48 | 1010 | 145 | |
400×200 | 8 | 13 | 16 | 84.12 | 66 | 23700 | 1740 | 16.8 | 4.54 | 1190 | 174 | ||
450×150 | 400×150 | 9 | 14 | 20 | 83.41 | 65.5 | 27100 | 793 | 18.0 | 3.08 | 1200 | 106 | |
450×200 | 446×199 | 8 | 12 | 20 | 84.95 | 66.7 | 29000 | 1580 | 18.5 | 4.31 | 1300 | 159 | |
450×200 | 9 | 14 | 20 | 97.41 | 76.5 | 33700 | 1870 | 18.6 | 4.38 | 1500 | 187 | ||
500×150 | 500×150 | 10 | 16 | 20 | 98.23 | 77.1 | 3850 | 907 | 19.8 | 3.04 | 1540 | 121 | |
500×200 | 496×199 | 9 | 14 | 20 | 101.3 | 79.5 | 41900 | 1840 | 20.3 | 4.27 | 1690 | 185 | |
500×200 | 10 | 16 | 20 | 114.2 | 89.6 | 47800 | 2140 | 20.5 | 4.33 | 1910 | 214 | ||
506×201 | 11 | 19 | 20 | 131.3 | 103 | 56500 | 2580 | 20.8 | 4.43 | 2230 | 257 | ||
600×200 | 596×199 | 10 | 15 | 24 | 121.2 | 95.1 | 69300 | 1980 | 23.9 | 4.04 | 2330 | 199 | |
600×200 | 11 | 17 | 24 | 135.2 | 106 | 78200 | 2280 | 24.1 | 4.11 | 2610 | 228 | ||
606×201 | 12 | 20 | 24 | 153.3 | 120 | 91000 | 2720 | 24.4 | 4.21 | 3000 | 271 | ||
700×300 | 692×300 | 13 | 20 | 28 | 211.5 | 166 | 172000 | 9020 | 28.6 | 6.53 | 4980 | 602 | |
700×300 | 13 | 24 | 28 | 235.5 | 185 | 201000 | 10800 | 29.3 | 6.78 | 5760 | 722 | ||
800×300 | 792×300 | 14 | 22 | 28 | 243.4 | 191 | 254000 | 9930 | 32.3 | 6.39 | 6400 | 662 | |
800×300 | 14 | 26 | 28 | 267.4 | 210 | 292000 | 11700 | 33.0 | 6.62 | 7290 | 782 | ||
900×300 | 890×299 | 15 | 23 | 28 | 270.9 | 213 | 345000 | 10300 | 35.7 | 6.16 | 7760 | 688 | |
900×300 | 16 | 28 | 28 | 309.8 | 243 | 411000 | 12600 | 35.4 | 6.39 | 9140 | 843 | ||
912×302 | 18 | 34 | 28 | 364.0 | 286 | 498000 | 15700 | 37.0 | 6.56 | 10900 | 1040 |
